TG36A GANG TYPE CNC LATHE

TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes
TG36A GANG TYPE CNC LATHE, Cnc Lathes

Warning: It is recommended that you do not make any payment (deposit, advance, etc.) before visiting the actual area (workplace, shop, etc.) where the advertiser offers his goods and services to the relevant parties and before receiving the goods and services you want to buy.

TG36A Gang Type CNC Lathe Product Features - Fanuc 0i-TF Plus 10.5" Operating System - Collet Type Hydraulic Chuck - Hydraulic Unit - 3 Colored Warning Lamp - Automatic Lubrication System - Belt Type Chip Conveyor and Trolley - Pencil Picker - 35mm - 2 Sets - Round Holder - 25mm Diameter - 2 Sets - Foot Pedal - Tool Case - Scale Feet - 2 Years Fanuc Warranty - 1 Year Mechanical Warranty Technical Specifications Maximum Turning Diametermm400 Maximum Turning Lengthmm300 Bar Capacitymm40 Chuck SizeInchClamp Spindle Motorukw5.5 Spindle Revolution/min4000 Work Spindle NormA2-5 Spindle Bearing Diam140 X Axis Movementm400 Z Axis Movementm300 X Axis Rapid Feed/min18 Z Axis Rapid Feed/d15 Slide TypeLinear Square Tool Sizem35 Round Tool Sizem25 Ground Requirement (LxL)mm2390x1530x1780 Weightkg2200
